GAS CONTROL PANEL

Nutec Bickley supplies Control Panels for local or remote operations. Gas Control Panels can be supplied with integrated PLC, ignition system, control logic and alarm signal. Gas control Panels are delivered prewired, tested at our facilities and also include ignition logic and all the required system alarms.

Request a quote

Each Gas Control Panel includes all internal logic sequence elements and controls such as timers, flame failure relays, power source, voltage regulation, control transformer, membrane swicth panel, ect. All Panels are designed using the safety guidelines of NFPA-86 “National Fire Protection Association” in its last edition.

Using the Gas Control Panel the process operator will be able to have full control over the system. Some of the functions he will be able to perform are:

  • Individual ignition for each burner
  • Flame failure detection
  • Automatic reset for flame relays
  • Display of each flame relay in order to identify failure modes using an LCD display
  • Detection of proper performance limits

FEATURES

  • Start up sequencel.
  • RAL color code.
  • Operation according to the highest quality and safety standards.
  • Visual and sound alarm.
  • Control panel with PID or PLC option.
  • Compliance with the latest NFPA-86 norm.
